Brainhack Kraków

BrainHack Kraków

Tools for reproducible workflows

Stephan Heunis

@fMRwhy

jsheunis

Psychoinformatics lab
Institute of Neuroscience and Medicine, Brain & Behavior (INM-7), Germany

Acknowledgements

A couple of things about me...

I'm a research software engineer at FZ Jülich. My background:

Studied engineering (robotics)
Worked for large company and then a tiny startup
Moved to the Netherlands to do a Phd in neuroimage processing
Started my current job at FZJ in Germany

I passionately like: open and inclusive science, programming, learning, a South African "braai"
I passionately dislike: hierarchies, systemic mysogyny/racism/ableism, any form of admin

A couple of things about me...

My biases:

A couple of things about YOU...

http://etc.ch/AHNN

A couple of things about YOU...

So let's talk about reproducibility

Reproducibility: what does it mean?

CC-BY Scriberia and The Turing Way

Reproducibility: what is needed?

An article about computational science in a scientific publication is not the scholarship itself, it is merely advertising of the scholarship. The actual scholarship is the complete ... set of instructions [and data] which generated the figures." David Donoho, 1998

http://statweb.stanford.edu/~wavelab/Wavelab_850/wavelab.pdf

Reproducibility: what is needed?

Transparency in methods

Reproducibility: why neuroscience?

Complex issues: Data

Neuroscientists acquire interesting data, but it has its peculiarities:

Depending on acquisition hardware and analysis software, some data are in proprietary formats (e.g., Neuromag, brain voyager, brain vision)
Depending on field, data can be sizeable (e.g., (f)MRI, CT, EEG, PET, MEG)
Heterogenous data from complex acquisitions with multiple data channels and modalities
Datasets are getting bigger and bigger ( Bzdok & Yeo, 2017), e.g. multi-modal imaging, behavioral + genetics data in HCP (humanconnectome.org) or UKBiobank (ukbiobank.ac.uk/)
Some data fall under General Data Protection Regulation (GDPR)

This makes data harder to access, structure, and share

Complex issues: analyses

Much of neuroscientific research is computationally intensive, with complex workflows from raw data to result, and plenty of researchers degrees of freedom

Poline et al., 2011

Complex issues: analyses

NARPS Study, Botvinik-Nezer et al., 2020	70 independent research groups, investigating 9 hypothesis, on the same data: Consistent conclusions for four hypothesis
The variety of methodological & analytical choices is not the enemy to computational reproducibility, the challenge lies in encoding those degrees of freedom in a standardized, ideally machine-readable way Gilmore et al., 2017

Complex issues: software/tools

Software is a part of the digital provenance of your work: Some analysis will only work in the desired way (or at all) in specific versions of a software
But it goes beyond "one software": Modern data analysis software has an incredibly complex dependency stack
Example Scikit-learn Direct dependencies: 38 packages, 153 dependency relations. Recursive dependencies: 485 packages, 10715 dependency relations

"Computation in science", Hinsen (2020)

Complex issues: infrastructure

"Works on my machine"

derickbailey.com

Complex issues: changes over time

Based on Piled Higher and Deeper 1531

Complex issues: changes over time

Piled Higher and Deeper 1323

Complex issues: changes over time

"This used to work on my machine..."

And if the analysis does not fail, but produces different results,
how do you know which is the correct one?

So what do we end up with?

Based on xkcd.com/2347/ (CC-BY)

So what do we end up with?

"Shit, which version of which script produced these outputs from which version of what data?"

CC-BY Scriberia and The Turing Way

What should we do about it???

The pipeline needs to become transparent

CC-BY Scriberia & The Turing Way

Digital Provenance = A complete description of how a digital file came to be (FAIR principles)

What should we do about it???

The pipeline needs to become automated

CC-BY Scriberia & The Turing Way

enshrine analysis
& workflows in
code, not clicks
Make workflow
execution easy,
e.g., with master
scripts to bundle
up individual steps

Perkel, 2020, checklist for
computational reproducibility

Don't panic!

Large & growing ecosystem of Open Source software & data formats

... and many more!

Remove accessibility barriers
Transparent digital provenance

And finally...the point of my talk:

Tools for reproducible workflows in neuroscience

A PhD student walks into a lab...

You've just published a paper that calculated the cortical thickness for a group of research participants. You've run some statistical tests and visualized the results.

A PhD student walks into a lab...

Soon after, a researcher in your field sends you an email:

A PhD student walks into a lab...

How do we approach this challenge? Which skills should we have to go...

from reacting like this:

to reacting like this:

A PhD student walks into a lab...

We are going to take a step-wise, "Galaxy brain" approach:

Step 1: share data and code

Why don't we just send them the data and code "via" a download link?

Step 1: share data and code

💬 Why don't we just send them the data and code "via" a download link?

You have to create a link and send an email every time someone requests it
There are no instructions included for running the analysis
The person might not have the correct software or package versions installed
They could perhaps figure out from the code which packages are required, but installing them might interfere with their existing environment, which might break things down the line.

Step 1: share data and code

So they tried running the script on their machine, and then...

💬 What went wrong? What should we have done?

Step 1: share data and code

To prevent this issue (or similar issues), while still allowing others to run the code on their machines, we need to share:

1.	The required packages	requirements.txt
2.	The Python version	virtual environment
3.	Instructions for how to use these to successfully run the script	README
4.	Data and code and all of the above in an accessible location	GitHub

Example GitHub Repository

Step 1: share data and code

Open (and free) data repositories, e.g. OpenNeuro:

Extended list of repositories

Step 1: share data and code

"Galaxy brain" update:

Step 2: software environment and requirements

After sharing the news about the public GitHub repo with our colleague, we get the following reply:

Now we'll focus on requirements and virtual environments

Step 2: software environment and requirements

Introducing requirements.txt

Single file to capture required Python packages
Makes installation straight-forward with pip:


                pip install -r requirements.txt

In the file, you can specify the required packages (check script) and versions:


                matplotlib==3.2.2
                numpy>=1.16.5
                pandas
                nibabel
                nilearn>=0.7.1
                sklearn
                brainspace

NOTE: not all packages/tools required for an analysis are necessarily Python packages, or if they are they might not be available on the Python Package Index (PyPI). This means that installing everything with pip and a requirements.txt file might not be sufficient

Step 2: software environment and requirements

Introducing requirements.txt

Check whether some packages/tools might have to be installed differently:

APT: for managing packages (retrieval, configuration and installation) on Unix-like computer systems
conda: Package, dependency and environment management for any language running on Windows, macOS and Linux

Add extra installation instructions to README


                git clone https://github.com/MICA-MNI/BrainStat.git
                cd BrainStat
                python3 setup.py build
                python3 setup.py install

Step 2: software environment and requirements

Introducing Virtual Enviroments

requirements.txt helps a lot, but what if the colleague already has some of these packages installed? 💬
Installing new packages or existing packages with different versions can interfere with their local Python setup, and cause errors.

XKCD

Step 2: software environment and requirements

Introducing Virtual Enviroments

It would be great if colleagues could install our package requirements in a clean and isolated environment ==> virtual environments!

virtualenv


                #!/bin/bash
                pip install virtualenv #install the package
                virtualenv --python=python3 mypythonenv #create a new virtual environment
                source mypythonenv/bin/activate #activate the virtual environment
                # now install your packages with pip and do the analysis
                deactivate #deactivate the virtual environment

miniconda


                #!/bin/bash
                # install miniconda using install files via link
                conda create -n mypythonenv python=3.6
                conda activate mypythonenv
                # now install your packages with conda and/or pip and do the analysis
                conda deactivate #deactivate the virtual environment

Step 2: software environment and requirements

So we send the update to our colleague:

Step 2: software environment and requirements

"Galaxy brain" update:

Step 3: cloudy containers

So you decide to chill out now that everything should be working, right? Unfortunately, our feeling of accomplishment is short-lived, because Professor Important Dude is back with another question..

Step 3: cloudy containers

And then you realise... many things. At the same time:

Damn, you forgot about the OpenGL/LibGL requirement
You really don't want to have another Zoom call
You absolutely don't want to have multiple Zoom calls forever

So you cry out in desperation: Why can't it just work on their machines?!

Step 3: cloudy containers

Introducing containers

As we've seen, sharing code and data and even the virtual environment setup may not be enough for reproducibility
Also, even for moderately complex projects, the size of the software dependency stack can be
An alternative is to take a snapshot of the whole computational environment, including operating system and all software dependencies, to allow reproducibility
Useful resources:

Step 3: cloudy containers

Introducing containers

Rachael Ainsworth
If we don't always want to have to explain how to install yet another tool, maybe we can run everything in the cloud...

Step 3: cloudy containers

Introducing Binder: mybinder.org

CC-BY Scriberia and The Turing Way

Step 3: cloudy containers

Example:

Step 3: cloudy containers

We can't hold our excitement, so we send a quick email to notify the colleague:

Step 3: cloudy containers

"Galaxy brain" update:

STEP 4: Interplanetary sci-comm

So, you're busy (rightfully) thinking that you have done a great job of making your work more reproducible, but then ... it looks like we spoke too soon. Our VIP friend has another request...

STEP 4: Interplanetary sci-comm

So firstly, it works for them!!! (Always try and celebrate the wins in academia, however big or small.)

Secondly, let's take a deeper look into this notebook thing.
And what's with Jupiter?

NASA SpacePlace

STEP 4: Interplanetary sci-comm

"The Jupyter Notebook is an open-source web application that allows you to create and share documents that contain live code, equations, visualizations and narrative text. Uses include: data cleaning and transformation, numerical simulation, statistical modeling, data visualization, machine learning, and much more."

Jupyter.org

STEP 4: Interplanetary sci-comm

Jupyter notebooks:

Can be installed (amongst other methods) with conda and pip


                conda install -c conda-forge notebook
                pip install notebook

Can work with kernels for Python, R, Octave, Julia and many more!
Form part of the bigger Jupyter ecosystem (including JupyterLab and JupyterHub)
If on a public repository, can be viewed statically with nbviewer
If on Binder, can be interacted with and edited in the cloud

STEP 4: Interplanetary sci-comm

This is what you have achieved!

Juliette Taka, Logilab and the OpenDreamKit project

STEP 4: Interplanetary sci-comm

"Galaxy brain" update:

STEP 5: Reproducible data management

In many cases we will work with large datasets and multiple analysis pipelines will form part of the full research pipeline, each with their own list of software and environment requirements. Managing the full reproducibility of such workflows can be challenging (or impossible) without the right tools that allow:

Data version control
Provenance capture

STEP 5: Reproducible data management

A command-line tool (and GUI!) with a Python API
Builds on top of Git and Git-annex

Allows...

... version-controlling arbitrarily large content,

... easily sharing and obtaining data (note: no data hosting!),

... (computationally) reproducible data analysis,

... and much more

Completely domain-agnostic
Available for all major operating systems (Linux, macOS/OSX, Windows): installation instructions
Detailed documentation: DataLad Handbook

STEP 5: Reproducible data management

"Galaxy brain" update:

So...
now you might feel like this

via GIPHY

But that is why brainhacks exist!

Learn
Collaborate
Make new friends and colleagues
Form a community
Improve science!
